Multichannel SRT encoder of ENC8 supports HDMI NDI encoder live streaming protocol IPTV head

ENC8 Multichannel SRT encoder is a 8 channel of 1080P embedded video and audio hardware encoder,It can be converted into a 12 channel IP transcoder. It applies H.265 and H.264 encoding standard (this standard is a digital video encoding standard made out by TTU-T and ISO). With this encoding standard,it can encode 9 channels of 1080P 60fps H 265 video and stereo audio simultaneously. It is inserted with DE-interlacing scanning algorithm, which makes video quality reach the best level. Compared with the present widely used H 264 encoding algorithm, ENC8 HDMI NDI encoder can save 30-50% of transmission bandwidth and storage space at the same video quality. It has the advantages of supporting international standards, high performance, flexible configuration and strong scalability. It is suitable for radio&TV operators, telecommunications operators, governments of different levels, and school etc.

ENC8 Multichannel SRT encoder applies 1U design is easy to carry, embedded OS(embedded operating system), supports 7×24 hours non-stopping work. Its platform is based on BS configuration structure; management and configuration are done by this web-page in the long-distance without being supervised by human.

ENC8 HDMI NDI encoder supported h 265 and h 264 standard,  Supported audio encoding formats are AAC, MP3, PCMA, etc, Support live stream protocol SRT,NDI,HTTP, HLS, RTSP, RTMP of flow push, RTMP pull flow, UDP, Multicast network protocol etc. And the one same channel can enable all network streams at the same time.

ENC8 Multichannel SRT encoder support timing recording and network storage,IPTV head h 265 video compressor of ENC8 supports 12 channel real-time transcoding function.

Technical Features

• Embedded hardware encoder
• H 265,H 264 Main profile
• Video input format 1080P,720P,1600×1200,1440×900,1366×768,1280x1024x1024x768,800×600,640×480
• Support High-bandwidth Digital Content Protection (HDCP)
• Audio output format AAC,MP3,PCMA
• Coding resolution 18x4K 30fps(3840*2160),1080P,720P,1600×1200,1440×900,1366×768,1280x1024x1024x768,800×600,640×480
• Support 9 channel online monitoring function
• Support CBR,VBR,AVBR
• Highest code rate 40Mbps
• Automatic scene change detection technology, improve the coding effect
• Every channel is inserted with de-interlacing scanning algorithm
• ENC8 HDMI NDI encoder can use space pre-treatment and block filtering technology for moving scenes
• ENC8 Multichannel SRT encoder do the recording duringthe set time and save the recorded files in the networks
• With dongle function, Monitor safe operation
• Support a variety of common platforms at home and abroad such as NDI,wowza, FMS, youtube,facebook,NJ and so on

Topology diagram of the overall scheme

Product Advantages

• SOC chip is even more powerful
• Mini design is easy to carry
• 8 channels 1080P 30fps of encoding
• Strong system stability
• Low cost of maintenance
• 7×24 non-stoping work
• Multi-media platforms

Software configuration picture

[ fusion_table]

Application Range

• Network video and audio broadcast based on IP protocol.
• Suitable for all kinds of video conference software developers, system developers to do the acquisition end
• Suitable for educational network, campus network TV broadcast, multimedia classroom broadcast, multimedia conference broadcast, and enterprises and institutions internal conference broadcast and other occasions;
• Live broadcast of stock appraisal in securities industry and stock market and remote training within enterprises
• Applicable to video live broadcast business of government, media industry and other portal websites
• Suitable for remote monitoring in public places and important monitoring areas
• Suitable for remote monitoring of military exercises and two-way audio-visual communication

NDI is a registered trademark of Newtek
